Mindray TE7T User Manual

Image Optimization 5-31
2
IVC CI
(Compressibility Index),
DI (Dilation Index), Resv
trend curve
Corresponds to the selected breath type:
 Spontaneous Breath: displays the CI curve.
 Mechanical Ventilation displays the DI and IVCV.
3
IVC Sampling Line
/
4
IVC Trending Line
The horizontal axis represents the time, which is displayed
in the below Free Xros M image, and is traced along the IVC
vessel wall.
5
Diagnostic Information
Displays the added diagnostic information.
6
Calculation Results
Window
Displays the calculation results within the current
calculation range.
 Dmax: indicates the maximum IVC inner diameter within
a respiratory cycle.
 Dmin: indicates the minimum IVC inner diameter within
a respiratory cycle.
 IVC CI = (Dmax-Dmin)/Dmax
 IVC DI = (Dmax-Dmin)/Dmin
 IVCV = (Dmax-Dmin)/[(Dmax+Dmin)/2]
