85
SP1B
SK73750/7
PG DRIVES TECHNOLOGY
20
display the TruCharge trip code. This is done by pulsing the lamp on for a number of
times equivalent to the number of TruCharge bars that would be flashing for a given
trip.
The information in Chapter 2 section 3.1.1, still applies, so for example, if an Egis with
this option enabled had a throttle trip, the status lamp would flash 7 times, pause
briefly, flash 7 times, pause briefly and so on.
7.2 Safety Fences
These allow minimum and maximum settings for acceleration, deceleration and
speeds to be held within the controller. The SP1 would then be unable to set parameters
outside these limits. The default safety fences are as follows:
Parameter
Forward Acceleration
Forward Deceleration
Reverse Acceleration
Reverse Deceleration
Forward Speed
Reverse Speed
0.1 secs
0.1 secs
0.1 secs
0.1 secs
0%
0%
10 secs
10 secs
10 secs
10 secs
100%
100%
Min Max
