3 Using The SP1b
Please read this guide carefully before using the SP1b Programmer.
Programming should only be conducted by competent
personnel with in-depth knowledge of PGDT electronic
controllers. Incorrect programming could result in an unsafe
set-up of a vehicle for a user. PGDT accept no liability for
losses of any kind if the programming of the controller is
altered from factory pre-set values.
3.1 Connection
The SP1 can be connected to the controller when the controller is switched either on
or off. You can also drive with the SP1 connected.
For safety reasons, accessing some critical parameters will
cause the controller to trip. This is intentional and the
controller can be reset by switching it off then on again.
3.1.1 Programming
To program, simply connect the SP1 to the controller whilst it is turned on. If the SP1 is
showing diagnostic information, press the ENTER key and the SP1 will go into
programming mode.
3.1.2 Diagnostics
To use the SP1 to view trip codes and messages, connect it to the controller when the
controller has tripped.
If a trip occurs when the SP1 is already connected, then no
diagnostic information will appear.
When the SP1 is connected to a controller, the electromagnetic
compatibility (E.M.C.) performance of the vehicle may be
affected. Disconnect the SP1 as soon as programming is
complete and do not use the SP1 in environments which are
E.M.C. sensitive.
