User Manual
Models: SC40T, SC40TNF, SC60T, and SC60TNF
2023 Page 12
SmartCube Shelf Replacement
Locate the lock bar located on the right side inner
wall of the minibar. Lift up on the locking bar to
unlock the sensor shelves from the backplane.
Slide out sensor shelves carefully and disconnect
from the backplane connectors to replace.
To Next Page
