User Manual
Models: SC40T, SC40TNF, SC60T, and SC60TNF
2023 Page 23
SmartCube SC-60 Anti-Tilt Bracket Installation
Make a case good per the specified
dimensional drawing for proper
ventilation. (Reference to the
dimensional drawings).
Fix the rear anchor bracket onto the case
good using the gauge template or refer
to the dimensional drawing for
mounting locations.
Screws(MB-NP-0023) packed in
accessory back along with the
bracket(MB-MP-0023).
To Next Page
