User Manual
Models: SC40T, SC40TNF, SC60T, and SC60TNF
2023 Page 7
Installation Instructions
These Installation Instructions are for guidance for all SmartCube models SC40T, SC40TNF, SC60T,
and SC60TNF units available.
Door Shelf Replacement
To remove the door-mounted shelf you will need
to first remove the rubber plug on the left side of
the door shelf column that is protecting the un-
used backplane connector.
Free the door racks from the plastic tab locking
features by squeezing onto the sides of the door
shelf column. Lift up on the door rack kit to release.
