User Manual
Models: SC40T, SC40TNF, SC60T, and SC60TNF
2023 Page 18
DualBar Anti-Tilt Bracket Installation
Make a case good per the
specified dimensional
drawing for proper
ventilation. (Reference to
the dimensional drawings).
Fix the rear anchor bracket
onto the case good using
the gauge template or refer
to the dimensional
drawing for mounting
locations.
Screws (MB-NP-0023)
packed in accessory back
along with the bracket
(MB-MP-0023).
