Minolta CL-200 User Manual

8
Preparation
Installing the Receptor Head
1. Attach the receptor head to the main body.
1. Hold down the receptor-head release button and pull the receptor
head off.
● Always set the power switch to the OFF position (the “ ”
side) before attaching or removing the receptor head. At-
taching or removing the head while the power is ON may
generate an error.
Removing the Receptor Head
The Minolta llluminance Meter allows you to take readings in either Lux (lx.) or Foot-candle
(fcd) units.
Selecting measuring units
1. Set the power switch to “ ” (OFF), and pull the battery cover while
pressing it down slightly.
2. Remove two AA-size batteries, if it exits.
3. Set the measuring-unit selector to the desired position (lx. or fcd).
4. Pull back those batteries and battery cover.
Display example
