11
SCRUB DECK
Minuteman offers two deck types (Cylindrical and Disc) to fit your specific needs. The
ES2832 design is very dynamic wherein the decks are interchangeable in a matter of minutes
whenever necessary (removal of four bolts, and two quick-connects). The cylindrical brush
deck has five built-in spray jets to uniformly dispense cleaning solution on the floor and a wet
sweeping debris tray to collect loose objects on the floor. The disc brush deck dispenses
cleaning solution through the center hub and contained within the bristle area for efficient
agitation of cleaning solution to the floor and channeled to the rear of the machine. The disc
brushes are also easily removed and installed with the quick release clamp by using any of the
three access doors. Another nice feature that these scrub decks have is the ability to have
uniform brush pressure applied to the floor at all times. Since the scrub deck brush pressure is
computer controlled, it will automatically adjust and compensate to uneven contours on the
floor while maintaining brush pressure.
CYLINDRICAL SCRUB DECK
A
B
C
D
E
F
G
H
I
J
K
L
M
Housing
Spray jets (5)
Access door (2)
Nut, Access door
Debris box
Connector, water
Mounting bracket
Connector, power
Brush motor (2)
Pulley cover (2)
Bolt (4)
Lock washer (4)
Flat washer (4)
