22
5 7700
SOFT VACUUM MOTOR
DISCONNECTED ERROR
5 7701 SOFT VACUUM CURRENT FOLDBACK
5 7702 SOFT VACUUM CURRENT FOLDBACK2
5 7703 SOFT VACUUM CURRENT FOLDBACK3
7 0810 TILLER FAULT-1 For all Tiller Diagnostic Codes:
7 0811
TILLER MAX WIPER DIFFERENCE
ERROR
7 0812
TILLER MAX PULL DOWN
DIFFERENCE ERROR
7 0813
TILLER MAX PULL SAFE DIFFERENCE
ERROR
7 0814 TILLER REFERENCE ERROR
7 0815 TILLER LO REFERENCE ERROR
7 0816 TILLER HI REFERENCE ISO ERROR
7 0817 TILLER LO REFERENCE ISO ERROR
7 0818 TILLER ERROR BOTH HAVE READINGS
1- Check throttle wiring for shorts or opens. Repair or
replace as necessary.
2- If Diagnostic Code is not cleared, then replace
throttle.
8 1310 EXCESSIVE CURRENT TRIP Disconnect Battery for 60 seconds. Reconnect battery
8 1311
SOFT AUX1 OVERCURRENT
OCCURRED
Device connected to Aux-1 exceeded current limit.
Check wiring or replace device.
8 1312
SOFT AUX2 OVERCURRENT
OCCURRED
Device connected to Aux-2 exceeded current limit.
Check wiring or replace device.
8 1313
SOFT AUX3 OVERCURRENT
OCCURRED
Device connected to Aux-3 exceeded current limit.
Check wiring or replace device.
8 1314
SOFT AUX4 OVERCURRENT
OCCURRED
Device connected to Aux41 exceeded current limit.
Check wiring or replace device.
8 1318
SOFT BRAKE LIGHT OVERCURRENT
OCCURRED
Brake light circuit exceeded current limit. Check wiring
or replace device.
8 131C
SOFT ALARM OVERCURRENT
OCCURRED
Alarm circuit exceeded current limit. Check wiring or
replace device.
8 1321 AUX1 OVERCURRENT 2 OCCURRED
Device connected to Aux-1 exceeded current limit.
Check wiring or replace device.
8 1322 AUX2 OVERCURRENT 2 OCCURRED
Device connected to Aux 2 exceeded current limit.
Check wiring or replace device.
8 1411
ERROR AUX 1 POSITIVE
SHORTED_LOW
Check Aux-1 wiring and device connected to Aux-1.
Repair or replace as necessary.
8 1412
ERROR AUX 1 NEGATIVE SHORTED
LOW
Check Aux-1 wiring and device connected to Aux-1.
Repair or replace as necessary.
8 1413
ERROR AUX 2 POSITIVE SHORTED
LOW
Check Aux-2 wiring and device connected to Aux-2.
Repair or replace as necessary.
8 1414
ERROR AUX 2 NEGATIVE SHORTED
LOW
Check Aux-2 wiring and device connected to Aux-2.
Repair or replace as necessary.
8 7900 EMERGENCY STOP ERROR Disconnect Battery for 60 seconds. Reconnect battery
9 1501 BRAKE FAULT 2
Check Brake circuit wiring and brake. Repair or replace
as necessary.
9 1507 BRAKE OVER CURRENT ERROR
Check Brake circuit wiring and brake. Repair or replace
as necessary.
10 1600 HIGH BATTERY ERROR Battery is overcharged or damaged. Replace battery.
Ripple 2F01 TILLER DISPLACED ERROR
Throttle displaced on Power-up. Release throttle and
then re-engage throttle.
Ripple 7901 SOFT BELLY BUTTON ACTIVATED Disconnect Battery for 60 seconds. Reconnect battery
