The unit must be returned in its original packaging.
MIR reserves the right to modify the instrument if required, and a description of any modification made will be
sent along with the returned goods.
Note
Any instrument of accessory returned must be accompanied by a clear and detailed explanation of the
defect or issue found.
6. TROUBLESHOOTING
Note
Where not indicated, voltages are measured versus the ground (i.e. the negative pole of the battery ).
Where not indicated, voltages are measured while the unit is switched on.
Where not indicated, the values to be measured can vary by about 2%.
WARNING
Be careful not to short-circuit any contacts while measuring voltages.
Batteries may explode if defective or damaged or disposed of in fire.
Do not short-circuit the batteries!
6.1. The device does not switch on
Check the integrity of the internal battery .
If the device is connected to the battery charger and the battery is disconnected or compromised, the display
shows the message:
Battery failure
If the battery charger is connected:
Check the battery charger:
– Make sure that the connector is fully inserted to the plug.
– Check the cable for visible damage.
Recharge battery
– Connect power cable to the device
– Check that the battery indicator on the display shows the correct charging phase
– When the charging is completed the battery indicator becomes green
6.2. The display remains black
Check that the flat connector of the display is not broken:
– Open the Spirolab (see Paragraph 4.2.1)
– Check that the connector is fully connected to the PCB
– Check that the flat is not excessively bent.
6.3. The battery is not working correctly
Check the battery charger
– Make sure that the main power supply’s connector is correctly attached to the plug.
– Check the cable for visible damage.
Check the internal power supply
– Open the Spirolab (see Paragraph 4.2.1).
– Measure the voltage at the output of the battery . It must be approximately between 3 V and 7,2 V.
