For oxy version: in addition to the components in the following table please consider the oxy module as follow:
Code
Description
PCB identification
001079
Oximetry module MIR046_B
\
List of Components
Code
Description
PCB identification
111588
Connettore plug alimentazione nero d = 2mm
J10
122005
Connettore maschio 2 pin 22035025 Molex
J1
123702
Connettore FCC 5597-04APB 4 pin 90° Molex
J2, J4
123704
Connettore FCC 5597-28APB 28 PIN 90° Molex
J3
123705_1
Connettore 40 pin OMRON XF2M-4015-1A passo 0.5mm
CONN1
123707
Connettore SMD Zif 10 pin pitch 1.0mm FCI SFW10R-1STAE1LF
J13
124005
Connettore SMD 10PIN (Femmina) per ossimetro
CON2
124007
Connettore SMD 10PIN (Femmina) per turbina spirolab IV
CON1
125003
Connettore USB tipo A verticale PTH Molex 894858003
J6
125004
Connettore SMD USB series Micro-AB SD-47590-001 top mount (
Molex )
J5
125500
Connettore RJ45 SMT low profile AMP 5406721_E
J8
130009
Connettore 6 pin dual row passo 2.0mm
J12
130011
Connettore 8 pin dual row passo 2.0mm
J12
130018
Connettore 2 pin strip maschio passo 2.54mm
JP1, JP2
130027
Connettore 8 pin pitch 1.27mm P/N.TMS-108-03-G-S-RA (Samtec)
J7
210858
Pulsante THT right angle FSM104 (Tyco) or equivalent P/N HSSA-
21N-V
S1
272408
Fusibile LF154002-RA000 Portafusibile 2A LF
F1, F2
272412
Fusibile LF154004-RA000 Portafusibile 4A LF
F3, F4
330017
Induttanza SMD 3.3 uH 7A 6.5x7 SPM6530T-3R3 (TDK)
L1
330018
Induttanza SMD 4.7 UH 1.2A 4x4 VLS4012 (TDK)
L6
330029
Induttanza SMD 220ohm@100MHz 0805 2A 25% MURATA
BLM21PG221SN1
L3, L4, L5
330100
Induttanza CDR125-101MC 100uH Sumida
L2
361600
Integrato SMD USB Vbus supply TPS2051C_SOT23-5 (TI)
IC6
450150
PCB MIR 080 rev2 spirolab IV
512489
Connettore backlight mating : SM02B-BHSS-1-TB
J11
560020
Buzzer OSCI PK12N40PE (dia.13.8 L.7.6)
SP1
600060
Diodo RB715 SMD 2/3 A UMD
D6, D7
602622
Diodo MRA4003T3G on semiconductor
D2
602632
Diodo SS34 Schottky 40V 3A
D4
602634
Diodo 1N4148W SMD package SOD 123
D5
602637
Diodo ES3A rectifier 50V 3A SMD
D1
610800
Transistor MMBF170LT1 MOSFET N SOT-23 Motorola
Q5
610900
Transistor XP132A1545SR MOSFET P SO-8 Torex
U6
610902
Transistor IRFU9024 MOSFET P DPACK IR
Q3
611930
Transistor MMBT3904LT1 NPN SOT-23 Rohm
TR1
