Keys, display, and menu guidance
No
.
Key icon Key name Description and Usage
1 Handset
2Display Color screen:
• top left: line number, name
1)
• top right: status display (displays symbols)
• bottom right: status notifications
• Middle: Display, depends on phone status
3 Message LED Color and status signal a specific event.
4 Navigation key with
selection key
Four directional keys (up, down, left, and right) on
the navigation cluster that can be used to navigate
through the various applications and settings
menus. The centre key acts as a Select button.
Horizontal navigation
keys
• Switching between the display in idle state and
line selection.
• Navigating in the options list.
Vertical navigation keys Navigating in the sub-menus of the options list.
Selection key • Selecting a menu item.
• Confirming settings.
5 End key
• Ending a call.
• Back to display in idle state.
• Exiting editor without changes.
6 Redial key Calling up the list of last dialed numbers.
7 Hold key • Holding an active call.
• Taking back a call from hold.
8 Mute key
Muting the microphone so that the caller cannot
hear you (the LED beside the key turns on when
the microphone is on mute).
9
Loudspeaker/headset
key with LED
• Activating/deactivating open listening.
• Activating/deactivating handset microphone.
• Activating/deactivating headset microphone.
10 Hash key Entering # or special characters.
11 Alphanumeric keys (A-Z,
a-z, 0-9)
Entering characters and digits.
