Mitel 6920 SIP - Page 13

Keys, display, and menu guidance
Mitel 6920 SIP 13
eud-1763/2.0 – R6.0 – 06.2018
12 Asterisk key Entering * or space.
13 Volume keys Adjusting volume.
14 Settings key Calling up a local settings menu (options list).
15 Voice mail Accessing your voice mail service.
16 Call history • Calling up the call history menu:
– unanswered
– answered
– redial list
17 Directory lookup Calling up the directory lookup.
18 Bottom softkeys S1-S18 Four freely configurable keys on which a total of
18 functions or call numbers can be configured.
Default functions are automatically set by the
MiVoice Office 400 communication system. You
can configure additional functions. If more than
four functions or call numbers are configured, the
fourth key is used to switch levels. Every fourth
function or call number is accessible at the next
level.
19 Rear:
• Connection for expansion key module.
• Connection for power supply.
• Connection for USB 2.0; this port can also be used to plug a headset with an
audio dongle.
• GigE dual connection for PC and LAN.
• Connection for headset.
• Connection for Power over Ethernet (PoE), class 2.
• Connection for wall mounting.
• Connection for magnetic keyboard.
No
.
Key icon Key name Description and Usage
