MITEL AG4100 ANALOG GATEWAY - QUICK INSTALLATION GUIDE
10 04/2024
2.2.5 MITEL AG4172 INDICATORS
Indicator Definition Status Description
PWR
Shows if the
Mitel AG4172
Analog Gateway is
on
On
The Mitel AG4172 Analog Gateway
is on.
Off
The Mitel AG4172 Analog Gateway
is off, or the power supply is
defective
RUN
Shows if the
Mitel AG4172
Analog Gateway is
working well
Slow flash
The Mitel AG4172 Analog Gateway
works properly
Fast flash
The SIP service is launched
Off
The Mitel AG4172 Analog Gateway
is working improperly
FXS
Shows if the port is
in use
On The FXS port is in use
Off The FXS port is inactive or defective
MGMT
Left LED: Shows if
the Mitel AG4172
Analog Gateway is
connected to the
network
Flash
The Mitel AG4172 Analog Gateway
is connected to the network
Off
The Mitel AG4172 Analog Gateway
is disconnected from the network, or
the network is defective
Right LED: Network
speed
On 100Mbs
Off 10Mbs
LAN
Left LED: Shows if
the Mitel AG4172
Analog Gateway is
connected to the
network
Flash
The Mitel AG4172 Analog Gateway
is connected to the network
Off
The Mitel AG4172 Analog Gateway
is disconnected from the network, or
the network is defective
Right LED: Network
speed
On 100Mbs
Off 10Mbs
