MITEL AG4100 ANALOG GATEWAY - QUICK INSTALLATION GUIDE
6 04/2024
2 PRESENTATION OF THE MITEL AG4100 ANALOG
GATEWAYS
2.1 MITEL AG4124 ANALOG GATEWAY
2.1.1 MITEL AG4124 FEATURES
The Mitel AG4124 is an Analog Gateway with:
• 24 FXS interfaces, accessible from:
o Either the front panel with 24 RJ11 connectors,
o Or the rear panel with 1 RJ21 connector.
• 3 LAN ports, 1 AUX port and 1 Console port (rear panel)
Front pa
nel
Rear panel
2.1.2 MITEL AG4124 DIMENSIONS AND WEIGHT
Dimensions
• Width: 44 cm (17,3”)
• Depth: 25 cm (9,8”)
• Height: 4,4 cm (1 ¾”)
Weight
• 3,2 kg (7lbs)
2.1.3 MITEL AG4124 LIMITATIONS
• Up to 12 lines out of the 24 lines supported by the Mitel AG4124 can ring or light MWI lights
at the same time.
