MITEL AG4100 ANALOG GATEWAY - QUICK INSTALLATION GUIDE
04/2024 9
2.2.4 MITEL AG4172 PORT TYPES AND PLUGS
Front panel
1 RJ48 RS232 Console port
2 RJ45 10/100Mb/s LAN ports
1 RJ45 10/100Mb/s Management port
1 AUX port
Rear panel
IEC-950 receptacle for the power cable
Grounding lug
3 RJ21 FXS analog ports for connecting up to 24 FXS
analog ports, from/
• 0 to 23,
• 24 to 47,
• 48 to 71
