MITEL AG4100 ANALOG GATEWAY - QUICK INSTALLATION GUIDE
04/2024 7
2.1.4 MITEL AG4124 PORT TYPES AND PLUGS
Front panel 24 RJ11 FXS analog ports, from 0 to 23
Rear panel
IEC-950 receptacle for the power cable
Grounding lug
RJ48 RS232 Console port
3 RJ45 10/100Mb/s LAN ports
1 AUX port
1 RJ21 connector for connecting up to 24 FXS analog
ports, from 0 to 23.
c
Note : The rear panel RJ21 connector may be used as an alternative to the front panel RJ11
connectors for connecting terminals.
2.1.5 MITEL AG4124 INDICATORS
Indicator Definition Status Description
PWR
Shows if the
Mitel AG4124
Analog Gateway is
on
On
The Mitel AG4124 Analog Gateway
is on.
Off
The Mitel AG4124 Analog Gateway
is off, or the power supply is
defective
RUN
Shows if the
Mitel AG4124
Analog Gateway is
working well
Slow flash
The Mitel AG4124 Analog Gateway
works properly
Fast flash
The SIP service is launched
Off
The Mitel AG4124 Analog Gateway
is working improperly
FXS
Shows if the port is
in use
On The FXS port is in use
Off The FXS port is inactive or defective
LAN
Shows if the
Mitel AG4124
Analog Gateway is
connected to the
network
Flash
The Mitel AG4124 Analog Gateway
is connected to the network
Off
The Mitel AG4124 Analog Gateway
is disconnected from the network, or
the network is defective
Network speed
Slow flash
100Mbs
Fast flash
10Mbs
