32/1531-ANF 901 43 Uen B2 2016-04-01
Installation Guide
Base Station
10
Connectors
• Two 8-pin RJ45 modular jacks for data and powering
• A 6-pin RJ12 modular jack for factory testing
LEDs
2.4 BS3X2
The following versions of the BS3x2 are available:
• BS332 with internal antenna
• BS342 with external antennas
The BS3x2 is backward compatible with the BS3x0 when it comes to coverage,
functionality, accessories and mounting bracket. If an old BS3x0 has to be replaced
you just reuse the mounting bracket and install the BS3x2.
Status of LED1 (lower LED) Description
Steady Green Power LED
Status of LED2 (upper LED) Description
Not lit Base station operational and no traffic on the
base station.
Flashing green Fully occupied with traffic.
Steady green Base station operational and traffic on the base
station.
Flashing amber Software is being downloaded to the base
station
Steady amber Base station is OK, but not available (self-test,
not initialized, no communication with PBX)
