Mitel Base Station - 2.1.2 IPBS440 WITH EXTERNAL ANTENNAS

32/1531-ANF 901 43 Uen B2 2016-04-01
Installation Guide
Base Station
3
Power Distribution
The IPBS4x0 can be powered using the following methods:
• Power over Ethernet, IEEE 802.3af
• A local AC-adapter
NOTE: For more information about power distribution, see 3.3 Power the Base Station
on page 22.
Software
The software in the IPBS4x0 can be updated by downloading new software without
disconnecting the equipment. The new software is stored in flash memory. For
information on how to update the software in the IPBS4x0, see the applicable
Installation and Operation Manual for the IPBS4x0.
Connectors
• Two 8-pin RJ45 modular jacks for LAN/PoE and powering
• A 6-pin RJ12 modular jack for factory testing
LEDs
2.1.2 IPBS440 WITH EXTERNAL ANTENNAS
The IPBS440 is available with two omni-directional external antennas. Other external
antennas can be mounted as well. This section contains the differences between the
IPBS4x0 with internal and external antennas. For all other information see 2.1.1
IPBS430 with Internal Antenna on page 2.
Status of LED1 (lower LED) Description
Steady Green Operational
Flashing fast amber Download of firmware in progress.
Steady Amber TFTP mode
Alternating red/green No Ethernet connection
Status of LED2 (upper LED) Description
Not lit IPBS 4x0 operational and no traffic on the IPBS
4x0.
Steady green IPBS 4x0 operational and traffic on the IPBS
4x0.
Flashing slow green Fully occupied with traffic.
Flashing red No air synchronization - searching for air sync
candidates.
Flashing fast red Download of RFP software in progress.
Alternating red/green RFP not initialized.
