32/1531-ANF 901 43 Uen B2 2016-04-01
Installation Guide
Base Station
2
2 DESCRIPTION
This section gives a general description of the following devices:
• IPBS4x0, see 2.1 IPBS4x0
• IPBS4x2, see 2.2 IPBS4x2 on page 4
• BS3x0, see 2.3 BS3x0 on page 8
• BS3x2, see 2.4 BS3x2 on page 10
2.1 IPBS4X0
The following versions of the IPBS4x0 are available:
• IPBS430
• IPBS440
2.1.1 IPBS430 WITH INTERNAL ANTENNA
Figure 1. IPB430 Overview
Contents of the Box
The box in which the IPBS430 is packed contains:
• An IPB430 with integrated antennas
• A mounting bracket
• Two screws with wall plugs
Test
(RJ12)
LAN
(RJ45)
Power Supply
(RJ45)
Front view Back view
LED1
LED2
005
Reset
