INSTALLING CHASSIS IN A CABINET
9 20/1531-ASP11301 Uen B5 2017-03-23
Table 2 Cabinet Frame (normally mounted)
2.2.4 POSITIONING THE CABINET
1. Make sure that holes for tip protection or earthquake bracing frame have been
drilled.
If not use the rack and the tip protection or the earthquake bracing frame as a
template.
2. Position the cabinet in line with other cabinets and the site walls, see the envi-
ronmental spec for MX-ONE SITE PLANNING.
1/BYB 501 180 Cabinet Frame
Pos. Title/Function Product Number Quantity
RACK FRAME, H=1800, METRIC, W=450 SXK 118 0444/1 1
MOUNTING BAR, H=1800, METRIC SXA 210 026/1 2
SCREW M 4X8 24/SBF 228 040/0080 24
A, B FOOT WITH ADJUSTING NUTS SXK 118 0159/1 4
DESIGNATION LABEL SVH 290 51/2 2
EARTHING PLATE SXA 123 0760/1 4
SCREW M 4X8 24/SBF 228 040/0080 8
PUSH-BUTTON SKY 117 01/4 2
SCREW 3.5X9.5 SBF 131 279/24 2
ESD WRISTSTRAP LYB 250 01/141 1
LABEL SVB 129 16 1
MARKING LABEL 2/SVF 191 040/2 1
MARKING PLATE2 SVF 191 131/1 1
