MELSEC-A
4. INSTALLATION AND PRE-OPERATION SETTING PROCEDURE
4 - 6
Number Name Description
8)
Terminal block
For the AJ65BT-D62D
Pin
Number
Signal name
Pin
Number
Signal name
1 DA 15
CH2
A
A
2 DB 16
A
3 DG 17
B
B
4 SLD 18
B
5 24V 19 PRESET
6 F.G. 20 COM
7 24G 21 F.START
8
CH1
A
A 22
CH1
EQU1
9
A
23 EQU2
10
B
B 24
CH2
EQU1
11
B
25 EQU2
12 PRESET 26 12/24V
13 COM 27 COM
14 F.START
For the AJ65BT-D62D-S1
Pin
Number
Signal name
Pin
Number
Signal name
1 DA 16
CH2
A
A
2 DB 17 A
3 DG 18
B
B
4 SLD 19 B
5 24V 20
PRESET
6 F.G. 21
PRESET
7 24G 22
F.START
8
CH1
A
A
23
9
A
24 CH1 EQU1
10
B
B
25 CH2 EQU1
11 B 26 12/24V
12
PRESET
27 COM
13
PRESET
14
F.START
15
