10. PROGRAMMING
10 - 3
(3) Set description
Set description of program examples for each function is shown below:
(a) Program example of coincidence output function
Set item Set description
CH. 1 pulse input mode/function selection
register/external output hold-clear settings (RWw2)
2-phase 2 multiplex
CH. 1 coincidence output point No. 1 set area
(RWw3, RWw4)
100
(b) Program example for preset execution with sequence program
Set item Set description
CH. 1 pulse input mode/function selection
register/external output hold-clear settings (RWw2)
2-phase 2 multiplex
CH. 1 preset value set area (RWw0, RWw1) 100
(c) Program example for preset execution with external control signal
Set item Set description
CH. 1 pulse input mode/function selection
register/external output hold-clear settings (RWw2)
2-phase 2 multiplex
CH. 1 preset value set area (RWw0, RWw1) 100
(d) Program example of ring counter function
Set item Set description
CH. 1 pulse input mode/function selection
register/external output hold-clear settings (RWw2)
2-phase 2 multiplex
CH. 1 sampling/frequency time set area (RWw6) 20000ms
(e) Program example of count disable function
Set item Set description
CH. 1 pulse input mode/function selection
register/external output hold-clear settings (RWw2)
2-phase 2 multiplex
(f) Program example of latch counter function
Set item Set description
CH. 1 pulse input mode/function selection
register/external output hold-clear settings (RWw2)
2-phase 2 multiplex,
latch counter function
