(g) Program example of sampling counter function
Set item Set description
CH. 1 pulse input mode/function selection
register/external output hold-clear settings (RWw2)
2-phase 2 multiplex,
sampling counter function
CH. 1 sampling/frequency time set area (RWw5) 20000ms
(h) Program example of frequency pulse counter function
Set item Set description
CH. 1 pulse input mode/function selection
register/external output hold-clear settings (RWw2)
2-phase 2 multiplex,
frequency pulse counter
function
CH. 1 sampling/frequency time set area (RWw5) 5000ms
