Mitsubishi Electric NZ2GN2B1-32D User Manual

1 PRODUCT LINEUP
1.1 List of Products
13
1
1 PRODUCT LINEUP
1.1 List of Products
Input modules
Module name Input specifications Module
power
supply
current
Weight Model Reference
DC input module Positive common/
negative common
shared type
Spring clamp terminal block
24VDC, 16 points
110mA 0.15kg NZ2GN2S1-16D Page 22
NZ2GN2S1-16D DC
input module
Spring clamp terminal block
24VDC, 32 points
110mA 0.20kg NZ2GN2S1-32D Page 25
NZ2GN2S1-32D DC
input module
Screw terminal block
24VDC, 16 points
110mA 0.21kg NZ2GN2B1-16D Page 28
NZ2GN2B1-16D DC
input module
Screw terminal block
24VDC, 32 points
110mA 0.31kg NZ2GN2B1-32D Page 31
NZ2GN2B1-32D DC
input module
40-pin connector
24VDC, 32 points
110mA 0.20kg NZ2GNCF1-32D Page 34
NZ2GNCF1-32D DC
input module
Positive common
type
Sensor connector (e-CON)
24VDC, 32 points
110mA 0.25kg NZ2GNCE3-32D Page 37
NZ2GNCE3-32D DC
input module
Waterproof connector
24VDC, 16 points
250mA 0.41kg NZ2GN12A4-16D Page 41
NZ2GN12A4-16D DC
input module
Negative common
type
Waterproof connector
24VDC, 16 points
250mA 0.41kg NZ2GN12A4-16DE Page 44
NZ2GN12A4-16DE DC
input module

Mitsubishi Electric NZ2GN2B1-32D Specifications

General

Category	Controller
Model	NZ2GN2B1-32D
Number of Inputs	32
Input Voltage	24 VDC
Mounting	DIN rail
Weight	0.2 kg
Isolation	Photocoupler
Connection Type	Terminal block
