8 FUNCTIONS
8.5 Output ON/OFF Information Hold Function
8.5 Output ON/OFF Information Hold Function
Checks whether the output has been turned on or off.
Output ON information
Output ON information is stored in Output Y ON information Y (RWrC, RWrD).
Whether the output has been turned on or not can be checked with Output Y ON information Y (RWrC, RWrD).
Output Y ON information Y (RWrC, RWrD) can be cleared using Output Y ON information clear request Y (RWwC,
RWwD).
The amount of time delay from when Output Y ON information Y (RWrC, RWrD) changes until the external output
accordingly changes is no more than the maximum output response time.
For the on and off timing, refer to the following.
Page 236 Output Y ON information
Output OFF information
Output OFF information is stored in Output Y OFF information Y (RWrE, RWrF).
Whether the output has been turned off or not can be checked with Output Y OFF information Y (RWrE, RWrF).
Output Y OFF information Y (RWrE, RWrF) can be cleared using Output Y OFF information clear request Y (RWwE,
RWwF).
The amount of time delay from when Output Y OFF information Y (RWrE, RWrF) changes until the external output
accordingly changes is no more than the maximum output response time.
For the on and off timing, refer to the following.
Page 237 Output Y OFF information
