3 SPECIFICATIONS
3.3 Performance Specifications
47
3
Output module
NZ2GN2S1-16T transistor output module
*1 Use bar solderless terminals for wiring.
*2 Only one wire can be inserted into a wire insertion opening. Multiple wires cannot be connected to a terminal. Connecting two or more
wires may cause a poor contact.
*3 This value indicates the number of points set by default when the module is dragged and dropped to the network map in the CC-Link IE
TSN Configuration window. According to the function used, set an appropriate number of points. ( Page 226 Output module (16-
point module))
Item NZ2GN2S1-16T
Station type Remote station
Authentication Class Authentication Class B
Network topology Line topology, star topology, mixture of star topology and line topology, ring topology
Number of output points 16 points
Rated load voltage 12/24VDC (ripple rate: 5% or less) (Allowable voltage range: 10.2 to 28.8VDC)
Max. load current 0.5A/point, 4A/common
Maximum inrush current Current is limited by the overload protection function.
Leakage current at OFF 0.1mA or less
Max. voltage drop at ON 0.3VDC (TYP.) 0.5A, 0.6VDC (MAX.) 0.5A
Output response time OFF ON 0.1ms or less
ON OFF 0.8ms or less (resistive load)
Surge suppressor Zener diode
External power supply
for output part
Voltage 12/24VDC (ripple rate: 5% or less) (Allowable voltage range: 10.2 to 28.8VDC)
Current 40mA or less (TYP. 24VDC per common) External load current is not included.
Withstand voltage 510VAC for 1 minute between all DC external terminals and ground
Insulation resistance 10M or higher between all DC external terminals and ground (500VDC insulation resistance tester)
Noise immunity Noise voltage 500Vp-p, noise width 1s, noise frequency 25 to 60Hz (DC type noise simulator
condition)
Protection degree IP2X
Wiring method for common 16 points/common (Common terminal: terminal number 18) (1-wire, spring clamp terminal block type)
Sink type
Protection function Overload protection
function
Limited current when detecting overcurrent: 1.5 to 3.5A/point
Activated to each point.
Overheat protection
function
Activated to each point.
External interface Communication part RJ45 connector
Module power supply
part
Terminal block for module power supply and FG (2-piece spring clamp terminal block)
I/O part 18-point two-piece spring clamp terminal block
Applicable wire size For power supply Stranded wire: 0.3 to 1.5 (22 to 16 AWG), terminal slot size: 2.4mm 1.5mm
*1
For I/O Stranded wire: 0.3 to 1.5 (22 to 16 AWG)
Applicable solderless
terminal
*2
Terminal block for
module power supply
and FG
Page 127 Applicable solderless terminal
Terminal block for output Page 136 Applicable solderless terminal
Multicast filter Available
Cyclic transmission RX/RY points 16 points
RWr/RWw points 4 points
*4
Module power supply Voltage 24VDC (ripple rate: 5% or less) (Allowable voltage range: 20.4 to 28.8VDC)
Current 110mA or less (24VDC, all points ON)
Weight 0.15kg
