Appendix 1 Remote I/O Signal
223
A
Details of remote input signals
The following describes the details of the remote input signals for the master/local module.
External input signal
■Device number
■Description
This signal shows the on/off status of the external input of input module and I/O combined module.
When a major or moderate error occurs in the I/O module, the external input signal turns off.
Details of remote output signals
The following describes the details of the remote output signals for the master/local module.
External output signal
■Device number
■Description
This signal turns on/off the external output of output module and I/O combined module.
When a major or moderate error occurs in the I/O module, external output turns off, regardless of the status of
the external output signal.
In addition, when either of the following conditions is applied, due to the output HOLD/CLEAR setting function,
external output may operate differently than the status of the external output signal.
• The I/O module is disconnected from the data link.
• The operation status of the CPU module is STOP or it is suspended by an error.
For details on the output HOLD/CLEAR setting function, refer to the following.
Page 156 Output HOLD/CLEAR Setting Function
Name Device number
External input signal X0 to external input signal X1F RX0 to RX1F
Name Device number
External output signal Y0 to external output signal Y1F RY0 to RY1F
