8 FUNCTIONS
8.3 CC-Link IE TSN Network Synchronous Communication Function
157
8
8.3 CC-Link IE TSN Network Synchronous
Communication Function
Performs I/O with a synchronization cycle of the master station that supports the CC-Link IE TSN Network synchronous
communication function.
This enables an I/O module to operate at the same timing as other slave stations on the same network.
The CC-Link IE TSN Network synchronous communication function has the following three modes.
• Synchronous X/Y control mode ( Page 159 Synchronous X/Y control mode)
• Synchronization cycle timing control mode ( Page 161 Synchronization cycle timing control mode)
• Set time synchronization control mode ( Page 165 Set time synchronization control mode)
Applicable version
When using the CC-Link IE TSN Network synchronous communication function, check the versions of I/O modules and
master stations that support this function.
■Synchronous X/Y control mode
• I/O module
• Master module
*1 The NZ2GN12A42-16DT and the NZ2GN12A42-16DTE do not support this mode.
•CPU module
Model Firmware version
NZ2GN2S1-32D, NZ2GN2B1-32D, NZ2GNCF1-32D, NZ2GNCE3-32D,
NZ2GN2S1-32T, NZ2GN2B1-32T, NZ2GNCF1-32T, NZ2GN2S1-32TE,
NZ2GN2B1-32TE, NZ2GN2S1-32DT, NZ2GN2B1-32DT, NZ2GNCE3-32DT,
NZ2GN2S1-32DTE, NZ2GN2B1-32DTE
"03" or later
NZ2GN2S1-16D, NZ2GN2B1-16D, NZ2GN12A4-16D, NZ2GN12A4-16DE,
NZ2GN2S1-16T, NZ2GN2B1-16T, NZ2GN12A2-16T, NZ2GN2S1-16TE,
NZ2GN2B1-16TE, NZ2GN12A2-16TE, NZ2GN12A42-16DT, NZ2GN12A42-
16DTE
"05" or later
Model Firmware version
RJ71GN11-T2 "10" or later
RD78G4, RD78G8, RD78G16, RD78G32, RD78G64, RD78GHV, RD78GHW "05" or later
*1
Model Firmware version
R00CPU, R01CPU, R02CPU "18" or later
R04CPU, R04ENCPU, R08CPU, R08ENCPU, R16CPU, R16ENCPU,
R32CPU, R32ENCPU, R120CPU, R120ENCPU
"50" or later
To Next Page
