2 PART NAMES
2 PART NAMES
This section describes part names of the I/O module.
• Spring clamp terminal block type
• Screw terminal block type
• 40-pin connector type
• Sensor connector (e-CON) type
(7) (9)(8) (8)
(1)
(6)
(2) (3) (4) (5)
(7) (9)(8) (8)
(1)
(6)
(2) (3) (4) (5)
(7) (11)(8) (8)
(1)
(6)
(2) (3) (4) (5)
(10) (11)(8) (8)
(1)
(6)
(3)(2) (4) (5)

Mitsubishi Electric NZ2GN2B1-32D Specifications

General

Category	Controller
Model	NZ2GN2B1-32D
Number of Inputs	32
Input Voltage	24 VDC
Mounting	DIN rail
Weight	0.2 kg
Isolation	Photocoupler
Connection Type	Terminal block
