Mitsubishi alpha 2 User Manual

α 2 Simple Application Controllers
Specifications 2
ENG-10
Table 2.4: Analog Input Specifications (Only AL2-***-D Type Unit)
Description Analog Input Specification
Number of Input Points
6 (I01 - I06) : AL2 - 10MR - D
8 (I01 - I08) : AL2 - 14MR - D,AL2 - 24MR - D
Analog Input Range 0 - 500
Resolution 9 bit, 20mV (10V/ 500)
Conversion Speed 8ms
Input Voltage 0 - 10V DC
Input Impedance 142kΩ ± 5%
Overall Accuracy ± 5% (0.5V DC)
Offset/Gain
Offset Value = 0 at 0V DC
Gain Value: 0 - 10V = 0 - 500
These default values can be changed in the OffsetGain FB
Temperature Drift ± 3 LSB
