Mitsubishi alpha 2 - Choosing Temperature Scale on AL2-2 PT-ADP

α 2 Simple Application Controllers
AL2-2PT-ADP 12
ENG-66
12.4.3 Choosing a Temperature Scale
1) Turn on the power to the α2 controller and select “Others...” from the TopMenu.
2) Select “Analog In” from the Others... menu.
3) Select “Temp. Scale” from the Analog In menu.
4) Choose “Celsius” or “Fahrenheit.” with the OK button
Only one system of units can be selected per controller.
The values under the Calibrate menu will remain in Celsius, regardless of the system
of units that is selected for the controller, as they are the labels for the jumper pins on
the Hardware.
TopMenu
ClockSet
LANGUAGE
Others. . .
Ot her s . . .
Se r i a l Com
Light Time
Ana l og I n
Ana l og I n
I07
I08
Temp . ca
Sle
Ana l og I n
Temp . Sca l e
Ce l s i us
Fahr enhe i t
