α 2 Simple Application Controllers
Key, System Bit and Function Block Lists 14
ENG-84
14. Key, System Bit and Function Block Lists
14.1 Key Lists
The following table is the keys to use operation in the Menu and user program. Further
information can be found in
α2 Programming Manual.
Table 14.1: Operation Key Lists
Key Name Key Number Description
OK K01 Acceptance of data entry, menu options, program choices
ESC K02 Cancel current operation, move to higher screen or menu
+K03
Connect function blocks, move to higher numbered blocks, increment
values
-K04
Disconnect function blocks, move to lower numbered blocks,
decrement values
K05
Scroll to higher number numbered items (keys, FB, Inputs, Outputs,
etc.)
K06 Scroll to lower numbered items (keys, FB, Inputs, Outputs, etc.)
K07 Move to the right on the LCD display, FB program or Jump command
K08 Move to the left on the LCD display, FB program or Jump command
