Mitsubishi ASX 2016

No.
Sym-
bol
Electrical sys-
tem
Ca-
paci-
ties
4
Windscreen
wipers
30 A
5 Option 10 A
6 Door locks 20 A
7 Radio 15 A
8
Control unit re-
lay
7.5 A
9
Interior lamps
(Room lamps)
15 A
10
Hazard warning
flasher
15 A
11
Rear window
wiper
15 A
12 Instruments 7.5 A
13
Cigarette lighter/
Accessory sock-
et
15 A
14 Ignition switch 10 A
15 Sunroof 20 A
*
: Fusible link
No.
Sym-
bol
Electrical sys-
tem
Ca-
paci-
ties
16
Outside rear-
view mirrors
10 A
17
4-wheel drive
system
10 A
18
Reversing lamps
(Backup lamps)
7.5 A
19
Accessory sock-
et
15 A
20
Electric window
control
30 A
*
21
Rear window
demister
30 A
*
22
Heated door
mirror
7.5 A
23
Passenger’s
power seat
25 (20) A
24
Driver’s power
seat
25 (20) A
25 Heated seat 30 A
*
: Fusible link
l
Some fuses may not be installed on your
vehicle, depending on the vehicle model
or specifications.
l
The table above shows the main equip-
ment corresponding to each fuse.
Engine compartment fuse loca-
tion table
Engine compartment fuse location
Behind of the fuse block cover
No.
Sym-
bol
Electrical sys-
tem
Ca-
paci-
ties
1 Front fog lamps 15 A
*
: Fusible link
Fuses
10-23
OGAE15E5
Maintenance
10
