Mitsubishi ECLIPSE CROSS 2017 User Manual

No.
Sym-
bol
Electrical sys-
tem
Ca-
pacity
2
Rear window
demister
30 A
*
3 Heater 30 A
4
Windscreen
wipers
30 A
5 Door locks 25 A
6 — — —
7
Accessory sock-
et
15 A
8
Rear window
wiper
15 A
9 Sunroof 20 A
10 Ignition switch 10 A
11 Option 10 A
12
Hazard warning
flasher
15 A
13
4-wheel drive
system
10 A
14
Stop lamps
(Brake lamps)
15 A
15 Instruments 10 A
*
: Fusible link
No.
Sym-
bol
Electrical sys-
tem
Ca-
pacity
16 SRS airbag 7.5 A
17 Radio 15 A
18
Control unit re-
lay
7.5 A
19
Interior lamps
(Room lamps)
15 A
20
Reversing lamps
(Backup lamps)
7.5 A
21
Heated door
mirror
7.5 A
22
Outside rear-
view mirrors
10 A
23
Cigarette lighter/
Accessory sock-
et
15 A
*
: Fusible link
l
Some fuses may not be installed on your
vehicle, depending on the vehicle model
or specifications.
l
The table above shows the main equip-
ment corresponding to each fuse.
Engine compartment fuse loca-
tion table
E01008002284
Fuse block
Behind of the fuse block cover
No.
Sym-
bol
Electrical system
Ca-
paci-
ty
1 Electric parking brake
30
A
*
*
: Fusible link
Fuses
10-19
OGKE18E1
Maintenance
10
