Electrical system
Ca-
paci-
ty
2 Electric parking brake
30
A
*
3
Anti-lock
braking system
30
A
*
4
Anti-lock
braking system
30
A
*
5 Power seat
30
A
*
6 Heated seat 30 A
7 Starter
30
A
*
8
Heated steering
wheel
15 A
9
Headlamp
washer
20 A
10 Security horn 20 A
11
Automatic
transmission
20 A
12 Horn 10 A
13 Sunshade 20 A
*
: Fusible link
No.
Sym-
bol
Electrical system
Ca-
paci-
ty
14
Front fog
lamps
15 A
15
Daytime running
lamps
10 A
16 Air conditioner 10 A
17
Engine control
unit
7.5 A
18 Alternator 7.5 A
19
Radiator fan
motor
40
A
*
20
Audio system
amp
30 A
21 — — —
22 IOD IOD 30 A
23
Air conditioning
condenser
fan motor
30
A
*
24
Battery current
sensor
7.5 A
*
: Fusible link
No.
Sym-
bol
Electrical system
Ca-
paci-
ty
25
/
Electric Parking
brake/Adaptive
Cruise
Control (ACC)
7.5 A
26
Headlamp
high-beam
(right)
10 A
27
Headlamp
high-beam
(left)
10 A
28 Turbo actuator 20 A
29 ENG/POWER 20 A
30 Fuel pump 15 A
31 Ignition coil 10 A
32 Injector 20 A
33 ETV 15 A
#1 — Spare fuse 10 A
#2 — Spare fuse 15 A
#3 — Spare fuse 20 A
*
: Fusible link
Fuses
10-20
OGKE18E1
Maintenance
10
