Mitsubishi FX-1PG - Page 62

<PC PROGRAM>
M8002
Initialed pulse
FNC 79
TO
K 0 K 0 K8192 K 1
FNC 79
TO
K 0 K 1 K1000 K 1
D
FNC 79
TO
K 0 K 3 H200E K 1
FNC 79
TO
K 0 K 4 K50000 K 1
D
FNC 79
TO
K 0 K 6 K 0 K 1
FNC 79
TO
K 0 K 7 K10000 K 1
D
FNC 79
TO
K 0 K 9 K10000 K 1
D
FNC 79
TO
K 0 K 11 K1500 K 1
FNC 79
TO
K 0 K 13 K 0 K 1
D
FNC 79
TO
K 0 K 15 K 100 K 1
FNC 79
TO
K 0 K 12 K 10 K 1
Writing of pulse rate
Writing of feed rate
Writing of parameters
Writing of maximun speed
Writing of bias speed
Writing of JOG speed
Writing of home position
return speed (high speed)
Writing of home position
return speed (creep speed)
Writing of number of zero
point signals for home
position return.
Writing of home position
Writing of accelaration/
deceleration time
10
FX-1PG/FX 2N -1PG PULSE GENERATOR UNIT EXAMPLES PROGRAM
