FX1S Series Programmable Controller Introduction 1
1-2
Table 1.3: DC Power Transistor Output Units
MODEL
INPUT OUTPUT
POWER
SUPPLY
DIMENSIONS
mm (inches)
MASS
(WEIGHT)
kg (lbs)
QTY TYPE QTY TYPE
FX1S-10MT-DSS 6
24V DC
Sink /
Source
4
Transistor
(Source)
24 VDC
+10, -15%
60
(2.4)
90
(3.5)
49
(1.9)
0.22
(0.48)
FX1S-14MT-DSS 8 6
FX1S-20MT-DSS 12 8
75
(3.0)
0.30
(0.66)
FX1S-30MT-DSS 16 14
100
(3.9)
0.35
(0.77)
