FX1S Series Programmable Controllers Power Supply 4
4-2
4.4 Power Supply Characteristics
*1 Includes the input current (5 or 7mA per point).
Table 4.2: DC Input Power Requirements, FX1S-**M*-DS, DSS
Table 4.1: AC Input Power Requirements, FX1S-**M*-ES/UL
Description FX
1S
-10M FX
1S
-14M FX
1S
-20M FX
1S
-30M
Power supply 100 - 240V AC, +10% -15%, 50/60 Hz
Max. allowable momentary
power failure period
10ms; if less than 10ms, the PLC will continue operation.
If 10ms or more, the PLC will shut down
Fuse (size) rating 250V 1.0A 5
φ×
20mm (0.2
×
0.79 inches)
In-rush current
100V AC - Max. 15A for 5ms
200V AC - Max. 25A for 5ms
Power consumption *1 19W 19W 20W 21W
24V DC Service Supply 400 mA
Description FX
1S
-10M FX
1S
-14M FX
1S
-20M FX
1S
-30M
Power supply 24 V DC +10% -15%
Max. allowable momentary
power failure period
5 ms; if less than 5 ms, the PLC will continue operation.
If 5 ms or more, the PLC will shut down
Fuse rating 0.8A
In-rush current 15A for 0.1 ms
Power consumption *1 6W 6.5W 7W 8W
