FX1S Series Programmable Controllers Outputs 6
6-3
6.2 Reliability Tests
The test results in Table 6.2 were gathered from a 1 sec ON/OFF test cycle. Please note that
the over current induced by in-rush greatly reduces the relay contacts service life. The rated
life for an inductive AC load such as a contactor or solenoid valve is 500,000 operations at
20VA.
Table 6.2: Relay Life Cycle Data
Description 20VA 35VA 80VA
Load capacity
0.2A/100VAC
0.1A/200VAC
0.35A/100V AC
0.17A/240V AC
0.8A/100V AC
0.4A/240V AC
Life of contact (cycles) 3,000,000 1,000,000 200,000
Example load (Mitsubishi contactor) S-K10 ~ S-K95 S-K100 ~ S-K150 S-K180,S-K400
