FX1S Series Programmable Controllers Diagnostics 7
7-12
Device Type Description
Counter
(32 normal and 21 High
Speed counters)
General Counter C0-C15 (16 pts)
Latched Counter C16-C31 (16 pts)
High Speed Counter C235-C255
Data register
(1500 pts, + 256 pts)
General Use Register D0-D127 (128 pts)
Latched Register D128-D255 (128 pts)
File Register D1000-D2499 (1500 pts)
Diagnostic Register D8000-D8255 (256 pts)
Index V0-V7, Z0-Z7 (16 pts)
Pointers
Pointer P0-P63 (64 pts)
Interupt Pointer I00… - I50… (6 pts)
Nest Level N0 - N7 (8 pts)
Numbers 16 bit 32 bit
K -32,768 to 32,767 -2,147,483,648 to 2,147,483,647
H 0 to FFFFH 0 to FFFFFFFFH
