FX2N Series Programmable Controllers Introduction 1
1-2
Table 1.3: ENG
☞
Powered extension units
FRE
☞
Appareils d’extension alimentés en tension
GER
☞
Spannungsversorgte Erweiterungsgeräte
ITL
☞
Apparecchi di ampliamento con alimentazione di tensione
ESP
☞
Unidades de ampliación con alimentación de tensión
MODEL
INPUTS OUTPUT TYPE
POWER
SUPPLY
DIMENSIONS
mm (inch)
MASS
(WEIGHT)
kg (lbs)
QTY TYPE QTY RELAY TRANSISTOR
FX
2N
-32 16
24V DC
Sink/Source
16
ER-
ES/UL
ET-ESS/UL
(Source)
100-240V AC
+10%, -15%,
50/60Hz
150 (5.91)
90
(3.55)
87
(3.43)
0.65 (1.43)
FX
2N
-48 24 24 182 (7.17) 0.85 (1.87)
FX
2N
-48 24 110V AC 24
ER-
UA1/UL
220 (8.67) 1.00 (2.20)
FX
2N
-48 24
24V DC
Sink/Source
24 ER-DS
ET-DSS
(Source)
24V DC
+20%, -30%
182 (7.17) 0.85 (1.87)
Table 1.4: ENG
☞
Extension blocks FRE
☞
Modules d’extension
GER
☞
Erweiterungsmodule ITL
☞
Moduli di ampliamento
ESP
☞
Módulos de ampliación
MODEL
INPUTS OUTPUTS
DIMENSIONS
mm (inch)
MASS (WEIGHT)
kg (lbs)
QTY TYPE QTY DEVICE TYPE
FX
0N
-8EX-UA1/UL
FX
2N
-8EX-UA1/UL
8
110V AC
inputs
43 (1.70)
90
(3.55)
87
(3.43)
0.20 (0.44)
FX
0N
-8EX-ES/UL
FX
2N
-8EX-ES/UL
Sink/Source
24V DC
FX
0N
-8ER-ES/UL
FX
2N
-8ER-ES/UL
44
Relay
FX
0N
-8EYR-ES/UL
FX
2N
-8EYR-ES/UL
8
FX
0N
-8EYT-ESS/UL
FX
2N
-8EYT-ESS/UL
8 Transistor Source
FX
0N
-16EX-ES/UL 16
Sink/Source
24V DC
70 (2.76) 0.30 (0.66)
FX
0N
-16EYR-ES/UL 16 Relay
FX
0N
-16EYT-ESS/UL 16 Transistor Source
FX
2N
-16EX-ES/UL 16
Sink/Source
24V DC
40 (1.58) 0.30 (0.66)
FX
2N
-16EYR-ES/UL 16 Relay
FX
2N
-16EYT-ESS/UL 16 Transistor Source
