FX2N Series Programmable Controllers Installation 3
3-13
1
2
3
4
5
6
7
A
B
C
∅
= 4.5mm (0.17")
3.7 General notes
General notes 3.7
Always ensure that mounted units and blocks are
kept as far as possible from high-voltage cables,
high-voltage equipment and power equipment.
Allgemeine Hinweise 3.7
Stellen Sie sicher, daß die Geräte und Module so
weit wie möglich entfernt von hochspan-
nungsführenden Leitungen, Anlagen und Span-
nungsversorgungen montiert werden.
Notas generales 3.7
Asegurar que las unidades y módulos, sean
instalados a la mayor distancia posible de cables,
instalaciones y unidades de alimentación de tensión
conductoras de alta tensión.
Instructions générales 3.7
Assurez-vous que les appareils et modules soient
montés le plus loin possible des lignes, installations
et alimentations en tension à haute tension.
Avvertenze generali 3.7
Accertatevi che gli apparecchi e i moduli siano
montati il più lontano possibile da conduttori,
impianti e alimentazioni di alta tensione.gen montiert
werden.
Table 3.4: ENG
☞
Hole positions FRE
☞
Positions des trous
GER
☞
Lochpositionen ITL
☞
Posizioni dei fori
ESP
☞
Posiciones de los agujeros
UNIT
W(mm) W(inches)
± 0.2 ± 0.01
D = W-8mm(0.32")
FX
2N
-8AD 67 2.64
E = W-24.5mm(0.97")
FX
2NC
-232ADP, FX
2NC
-485ADP 65.5 2.58
F = W-10mm(0.40")
FX
0N
-16E
✩
60 2.37
FX
2N
-16CCL-M 75 2.96
7(0.28")
19.1(0.76")
16.1(0.64")
74(2.92")
E
10
(0.40")
W
W
75(2.96")
D
90(3.55")
98(3.86")
FX0N-16EX-ES
POWER
IN01 234567
01234567
W
87(3.43")
F
W
9(0.36")
F
80(3.15")
90(3.55")
80(3.15")
90(3.55")
ENG
GER
ESP
FRE
ITL
