Mitsubishi FX2N series User Manual

FX2N Series Programmable Controllers Inputs 5
5-8
5.2.2 Typical wiring
Typical wiring 5.2.2
Verdrahtungsbeispiel 5.2.2
Ejemplo de cableado 5.2.2
Exemple de câblage 5.2.2
Esempio di cablaggio 5.2.2
Figure 5.5: ENG
☞
Ty p i ca l wir in g F R E
☞
Exemple de câblage
GER
☞
Verdrahtungsbeispiel ITL
☞
Esempio di cablaggio
ESP
☞
Ejemplo de cableado
ENG
GER
ESP
FRE
ITL
X0 X1 X2 X3
1
3
4
L N
COM COM
2
X3X2X1X0
2
Table 5.5: ENG
☞
Item check FRE
☞
Description du poste
GER
☞
Positionsbeschreibung ITL
☞
Descrizione della posizione
ESP
☞
Descripción de posición
REF.
➊
AC service supply
(see section 4.5)
Tension de service CA AC-Service-Spannung
Tensione di servizio
AC
Tensión de servicio CA
➋
Switch Interrupteur Schalter Interruttore Interruptor
➌
MPU
main processing unit
(base unit)
Appareil de base
API
SPS-Grundgerät
Apparecchio base
PLC
Unidad base PLC
➍
Extension block Module d’extension Erweiterungsmodul
Modulo di
ampliamento
Módulo de ampliación
ENG
FRE GER ITL ESP

Mitsubishi FX2N series Specifications

General

Type	Programmable Logic Controller (PLC)
Manufacturer	Mitsubishi Electric
Series	FX2N
Power Supply	100-240VAC or 24VDC
Program Capacity	8, 000 steps
Expansion	Yes, via expansion modules
Operating Temperature	0 to 55°C
I/O Points	16 to 256 points
Communication	RS-422, RS-485
Programming Language	Ladder Logic
Instruction Execution Speed	0.08 µs/basic instruction
Mounting	DIN rail
Data Memory	8, 000 words
Expansion Modules	Analog, digital, communication
Humidity	5 to 95% RH (non-condensing)
