3)
The operating state of the ACPU of a monitoring slave station is
displayed by the following message:
(The contents of the special registers for link D9212
to
D9215 are
disptayed.)
c
CPU RUN :When the ACPU
is
in the RUN state.
CPU STOP
:
When the ACPU is in the STOP
or
PAUSE state.
4)
When the monitoring slave station is 3-tier master station, it is
displayed on a remote
I/O
station whether an
I/O
allocation
is
correct
or
not.
(The contents of the special registers for link D9220
to
D9223 are
displayed.)
-
..
0
:
Normal
E
:
Error
5)
It
displays whether the monitoring local station could find that an
error occurred
in
other local stations.
(The contents of the special registers for link D9216
to
D9219 are
displayed.)
0
:
Normal
E
:
Error
"0"
is displayed When the monitoring station is a remote
I/O
station.
6)
The state of a positive loop line
(F
loop)
or
the reverse loop line
(R
loop)
of
a monitoring slave station is displayed.
(The contents of the special registers for link D9232
to
D9239 are
displayed.)
0:
Normal
E: Error
(4)
When it is connected
to
a local station, the loop state, BWY receive state,
and the operating state
of
other slave stations can be displayed.
(a) Loop state display (b) BWY receive status (c) Display of the oper-
display ating state of an-
other station
\
I
c
OTHER
LOCAL
STATUS
1
---
3
RUN
I
4
1)
The station number of the self and the number of connected slave
9
i
I
stations are displayed.
(The contents of the special registers
for
link D9243 and D9244
b
are displayed.)
H
[Ln]
:
In the case of a local station
[Rn]
:
In the case
of
a remote
I/O
station
m
:
Number of connected slave stations
6
-
76
