App - 4
(a) Switch 1
(b) Switch 2
Set value Description Remark
0000
H
Run mode Mode for executing the BASIC program.
0001
H
0002
H
Multitask debug mode Mode for debugging by connecting a debugger.
0003
H
0004
H
Programming mode Mode for programming by connecting a console.
0005
H
to 000F
H
Setting prohibited -
b7 b6 b5 b4 b3 b2 b1 b0
Bit
position
OFF(0) ON(1)
b0
b1
Refer to
*1
b2
Console
Not used Used
b3 Not used
b4 Console, debugger type VT VG
b5 Ctrl + C setting Disabled Enabled
b6 Not used
b7
*1 Console (Channel setting)
Bit position
b1 b0
Contents
OFF OFF Without console
OFF ON With console CH.1
ON OFF With console CH.2
ON ON Setting impossible
bF bE bD bC bB bA b9 b8
Bit
position
Contents OFF(0) ON(1)
b8 Not used Fixed on OFF
b9 Flash ROM write protection setting Without With
bA
bB
Not used Fixed on OFF
bC
bD
Channel setting Refer to *2
bE
Debugger
Software Not used Used
bF Not used Fixed on OFF
Bit position
bD bC
Contents
OFF OFF Without a debugger
OFF ON With debugger CH.1
ON OFF With debugger CH.2
ON ON Setting impossible
Contents
Channel setting
Access possible time setting after Y reset 200 ms 2000 ms
Fixed on OFF
Fixed on OFF
Software
*2 Debugger (Channel setting)
