Mitsubishi S3L2 Service Manual

133 / 195
Service Manual Mitsubishi SL-Series diesel engines
Version 08/2004
AUTOMATIC GLOW SYSTEM
ENGLISH
ELECTRICAL SYSTEM
33.3 Glow plug relay specifications
(standard)
2
33.4 Glow plug inspection
Test for continuity between the terminal and body as
shown in the illustration. If no continuity, replace with
new one.
Figure 202 Glow plug relay
2. All specifications are subject to change without any prior
notice.
Part number MM431-28201
Rated voltage DC 12 V
Continuous rating 1 minute
Coil resistance 13 Ω
Operating temperature
range
–40°C to +100°C
(–40°F to +212°F)
Figure 203 Testing glow plug
Item Standard
Resistance 0.55 Ω

Mitsubishi S3L2 Specifications

General

Engine Model	S3L2
Aspiration	Naturally aspirated
Cooling System	Water-cooled
Displacement	1.318 L
Bore x Stroke	78 mm x 92 mm
Starting System	Electric starter
Lubrication System	Forced lubrication by trochoid pump
