Mitsubishi S3L2 Service Manual

180 / 195
Service Manual Mitsubishi SL-Series diesel engines
Version 08/2004
ENGLISH
FUEL FILTER MAINTENANCE
180 / 195
MAINTENANCE
50 FUEL FILTER
50.1 Fuel filter with [AIR] valve
Close the fuel filter valve. Loosen the ring nut and take
out the element for cleaning or replacement.
50.2 Cartridge (air vent screw) type
fuel filter
Replace the filter as an assembly if water and sediment
have been accumulated in it.
Figure 264 Fuel filter with [AIR] valve
Valve lever
Element
Ring nut
Figure 265 Cartridge type fuel filter

Mitsubishi S3L2 Specifications

General

Engine Model	S3L2
Aspiration	Naturally aspirated
Cooling System	Water-cooled
Displacement	1.318 L
Bore x Stroke	78 mm x 92 mm
Starting System	Electric starter
Lubrication System	Forced lubrication by trochoid pump
