Service Manual Mitsubishi SL-Series diesel engines
Version 08/2004
ENGLISH
GENERAL AIR INLET SYSTEM AND EXHAUST SYSTEM
166 / 195
AIR INLET SYSTEM AND EXHAUST SYSTEM
44 GENERAL
44.1 Schematic
Air (from air cleaner)
Air breather pipe (for recirculation of blowby gases
Air inlet cover
Exhaust manifold
Blowby gases
To exhaust muffler
Figure 247 Schematic overview
